ITEM |
UNIT |
Specification Value |
Typical Value |
|
Tensile Strength |
MPa |
≥13.5 |
20 |
|
Elongation at Break |
% |
≥350 |
400 |
|
Air Aging Condition (135℃×168h) |
H
|
|
|
|
Tensile Strength Variation After Aging |
%
|
±20
|
-8
|
|
Elongation Variation After Aging |
% |
±20 |
-10 |
|
Hot Set Test Condition |
% |
≤100 |
80 |
|
Permanent Deformation after Cooling |
%
|
≤5
|
5
|
|
Brittle Temperature with Low Temperature |
℃
|
-76
|
-76
|
|
Impact Brittle Temperature |
Failures |
≤15/30 |
2/30 |
|
Volume Resistivity 20℃ |
Ω ·m |
≥1.0×1014 |
3.0×1014 |
|
Dielectric Strengthz |
MV/m |
≥25 |
30 |
|
Dielectric Constant |
|
≤2.35 |
2.32 |
|
Dissipation Factor |
|
≤1.0×10-3 |
8.0×10-4 |
It used for the insulation of low-voltage cables and control cables for 3kV and below.
